84.0 Amps 48V DC 5G Network Equipment Powerful Eltek Flatpack2 For Broadband / Network Access

Eltek Flatpack2 24/2000 241115.200 Flatpack2 24/2000 Rectifier Module

Specifications

Eltek Flatpack2 24/2000 241115.200
Flatpack2 24/2000 rectifier module
Versatile and powerful solution for any application
The combination of cost-effective design, power density and
Reliability makes the Flatpack2 a product family that truly stands
Outs and provides unparalleled network availability. The versatility
Of the Flatpack2 rectifier means that it can be used in a wide
Variety of 48VDC and 24VDC applications across the globe.

Application:

1. Wireless, fiber and fixed line communication
2. Broadband and network access
3. Small and large
Flatpack2 rectifiers are used in system solutions from 5kW to 96kW.

Additional Technical Specifications

Flatpack2 24/2000
Input:
85-290 VAC (Nominal 176 - 275VAC)
Output Voltage:
26.7V DC (adj. Range: 21.0-29.0 VDC)
Out Power:
2000 W at nominal input
1800 W at nominal input above 28.0 VDC
Safety Approval:
IEC 60950-1
UL 60950-1
CSA 22.2
Dimensions:

109 X 41.5 X 327mm (wxhxd)
(4.25 X 1.69 X 13")
Weight:

1.950 kg (4.3lbs)

Ordering Information:

Eltek Flatpack2 24/2000 (Code: 241115.200) 24V 2000W Telecom Rectifier Module

48VDC Eltek Flatpack2

2000W Eltek Flatpack2

241115.200

84.0 Amps 48V DC 5G Network Equipment Powerful Eltek Flatpack2 For Broadband / Network Access Images
